Classification Characteristics and Device Requirements of Cable Bridge Frames

電纜橋架可以分爲槽式、托盤式與梯架式，網格式等等，它是由支架，托臂與裝置附件所組成，電纜橋架的品種有什麼?裝置要留意些什麼?以上去爲大家闡明電纜橋架的分類跟裝置要求。

Cable bridge can be divided into trough type, tray type and ladder type, grid type and so on. It is composed of bracket, bracket and device accessories. What kind of cable bridge? What should the device pay attention to? The above is to clarify the classification and device requirements of cable bridge.

1、梯階式電纜橋架

1. Stepped Cable Bridge

梯級式電纜橋架是按照著及國外的相關材料，改良設計的，這種橋架運用起來本錢比擬低，搬起來分量輕，造型比擬特別，散熱好且透氣佳，通常用在直徑比擬大的電纜，較爲合適高或是高壓動力電纜。

The cascade cable bridge is improved and designed according to the international and foreign related materials. This kind of bridge has low cost, light lifting weight, special shape, good heat dissipation and good ventilation. It is usually used in cables with large diameter, which are suitable for high-voltage power cables or high-voltage power cables.

2、托盤式電纜橋架

2. Tray Cable Bridge

優點是分量很輕，負分量很大，造型美觀而且構造很簡潔，裝置也不大困難，通常用在石油，化工，輕工，電訊等，合適動力電纜的裝置，也可以用于控制電纜。

The advantages are light weight, large negative weight, beautiful appearance and simple structure, and the device is not too difficult. It is usually used in petroleum, chemical industry, light industry, telecommunications, suitable power cable devices, can also be used for control cables.

電纜橋架的分類特點和裝置要求

Classification Characteristics and Device Requirements of Cable Bridge Frames

3、槽式電纜橋架

3. Trough Cable Bridge

這是一種完全封鎖的電纜橋架，合適有高靈敏零碎的控制電纜，像是計算機電纜，通訊電纜等等，它可以很無效的屏蔽控制電纜的攪擾，與環境中的重腐蝕，有超級好的維護效果。

This is a completely blocked cable bridge. It is most suitable for high sensitive and fragmentary control cables, such as computer cables, communication cables, etc. It can effectively shield the disturbance of control cables, heavy corrosion in the environment, and has super good maintenance effect.

4、大跨距電纜橋架

4. Long Span Cable Bridge Frame

運用壽命長，且裝置比擬復雜，本錢比擬低，切割容易，是不需求維護，運用起來特別的方便，它是由拉擠玻璃鋼型材組裝起來的，可以用在電力電纜，控制電纜，照明電纜或是其他配件上。

The utility model has the advantages of long service life, complex device comparison, low cost comparison, easy cutting, no maintenance requirement and special convenience in use. It is assembled by pultruded FRP profiles and can be used in power cables, control cables, lighting cables or other accessories.

5、組合式電纜橋架

5. Composite cable bridge

電纜橋架的分類特點和裝置要求

Classification Characteristics and Device Requirements of Cable Bridge Frames

照著現場的裝置隨意轉向，可以變寬，分引上，引下，在隨意的部位不必打孔，不必焊接就把可用管引出，它是屬于一種新型的橋架，是電纜橋架中的第二代新產品，運用于各項工程，各個單位，方便工程中的設計，也方便消費時的運輸，是一個很的產品。

It is a new type of bridge frame and the second generation of new products in cable bridge frame. It is used in various projects, units, convenient for design in engineering, and convenient for transportation in consumption. It is a very excellent product.

裝置要求

Device requirements

1、電纜橋架跟要用電的設備遇到時，間距要大于0.5公尺。

1. The distance between the cable bridge and the equipment to be used should be greater than 0.5 meters.

2、兩組電纜在同一個高度平行時，間距要大于0.6公尺。

2. When two groups of cables are parallel at the same height, the spacing should be greater than 0.6 meters.

3、布放在線槽的纜線時，線槽外面的纜線要順直。

3. When laying the cable in the groove, the cable outside the groove should be straight.

4、在吊頂外面設置的時分，槽蓋開啟的那一面要堅持80毫米的垂直凈空，線槽截面的應用率要小于百分之五十。

4. When setting outside the ceiling, the opening side of the groove cover should adhere to the vertical clearance of 80 mm, and the application rate of the line groove section should be less than 50%.

綜上所述有濟南航豐實業有限公司提供，更多山東電纜橋架知識，歡迎關注我們的網站：http://tjmhgx.com謝謝支持!

In summary, Jinan Hangfeng Industrial Co., Ltd. provides more knowledge of Shandong cable bridge. Welcome to our website: http://tjmhgx.com. Thank you for your support!
