Cable trays can be used everywhere in our life. They protect cables from being damaged by the outside world, and there are many different types of cable trays. It is understood that the surface treatment methods of different cable trays are different. Different cable trays are used in different environments. Let's look at the differences in surface treatment of cable trays.

熱鍍鋅電纜橋架：成品酸洗-水洗-加助鍍液-烘干-掛鍍-冷卻-藥化-清洗-打磨熱鍍鋅完工。是一種有效的金屬防腐方式，主要用在每個行業的金屬結構設施上。是將除銹后的鋼件浸入500℃左右融化的鋅液中，使鋼構件表面附著鋅層，從而起到防腐的目的

Hot dip galvanized cable tray: finished product Pickling - water washing - adding auxiliary plating solution - drying - hanging plating - cooling - medicating - Cleaning - polishing hot dip galvanizing is completed. It is an effective metal corrosion prevention method, mainly used in metal structure facilities in every industry. It is to immerse the derusted steel parts into the molten zinc at about 500 ℃, so that the zinc layer is attached to the surface of the steel members, so as to achieve the purpose of corrosion prevention

在這里告訴大家熱噴鋅涂層表面由分布均勻的鋅粒組成，其粗糙程度對噴漆具有很好的附著力，使漆面不易脫落。同時又不會造成漆面不光滑而影響美觀。 熱噴鋅不會對工件造成變型。 因為熱噴鋅只在工作表面產生瞬間高溫，不會任何工件發生形變。

Here we tell you that the surface of the hot sprayed zinc coating is composed of evenly distributed zinc particles, and its roughness has good adhesion to the paint, so that the paint surface is not easy to fall off. At the same time, it will not cause the paint surface to be not smooth and affect the appearance. Hot spraying zinc will not cause deformation to the workpiece. Because the hot spraying zinc only produces instantaneous high temperature on the working surface, it will not cause deformation to any workpiece.

噴塑電纜橋架：是將塑料粉末噴涂在電纜橋架上的一種表面處理方法。不需稀料，施工對環境無污染，對人體害;涂層外觀質量優異，附著力及機械強度強;噴涂施工固化時間短;涂層耐腐耐磨能力高出很多;不需底漆;施工簡便，對工人技術要求低;成本低于噴漆工藝;有些施工場合已經明確提出使用靜電噴塑工藝處理;靜電噴粉噴涂過程中不會出現噴漆工藝中常見的流淌現象。

Spray plastic cable tray: it is a surface treatment method of spraying plastic powder on the cable tray. No thinner is required, the construction will not pollute the environment and will not harm the human body; The coating has excellent appearance quality, strong adhesion and mechanical strength; The curing time of spraying construction is short; The corrosion and wear resistance of the coating is much higher; No primer is required; Simple construction and low technical requirements for workers; The cost is lower than the painting process; Some construction sites have clearly proposed the use of electrostatic spraying process; There will be no common flow phenomenon in the process of electrostatic powder spraying.

冷鍍鋅電纜橋架：是利用電解設備將電纜橋架經過除油酸洗、后放入成分為鹽的溶液中，并連接電解設備的負極，在電纜橋架的對面放置鋅版，連接在電解設備的正極接通電源，利用電流從正極向負極的定向移動就會在電纜橋架上沉積一層鋅，冷鍍電纜橋架是先加工后鍍鋅。

Cold galvanized cable tray: it is to use the electrolytic equipment to wash the cable tray with oleic acid and then put it into the solution containing salt, connect the negative electrode of the electrolytic equipment, place a zinc plate on the opposite side of the cable tray, connect the positive electrode of the electrolytic equipment to the power supply, and use the current to move from the positive electrode to the negative electrode to deposit a layer of zinc on the cable tray. The cold galvanized cable tray is processed first and then galvanized.

防火電纜橋架：防火橋架外觀與噴塑橋架比較相似，不過性能完全不同，防火橋架主要性能是防火，有一定的防火等級，常用于有防火要求的場所，表面粗糙，表面摸起來會有粗糙斜斜的感覺，當遇到火災后不會燃燒，并且可以阻隔火勢繼續蔓延下去，起到一定的防火作用，防火涂層可以針對施工環境設計去選擇橋架的顏色。

Fire resistant cable tray: the appearance of fire-resistant cable tray is similar to that of spray plastic tray, but the performance is completely different. The main performance of fire-resistant cable tray is fire protection. It has a certain fire rating. It is often used in places with fire protection requirements. The surface is rough and the surface feels rough and oblique. It will not burn in case of fire, and can prevent the fire from continuing to spread, playing a certain fire protection role, The fireproof coating can be designed to select the color of the bridge according to the construction environment.

以上就是為大家介紹的有關電纜橋架的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://tjmhgx.com

The above is the detailed introduction of the cable tray for you. I hope it will help you. If you have any questions, please contact us. We will provide you with services with a professional attitude http://tjmhgx.com
